Ball Screw for Electric Azimuth / Elevation Marine Gun Actuators

  • DESCRIPTION

    • High-strength stainless steel, ball nut with no openings
    • Single start ball thread, ground execution
      according to accuracy class P1 - P5
    • Customized journals and bearing surfaces, laser-welded shafts
    • Diameter: 3 – 80 mm
    • Lead: 0.5 – 80 mm
    • Lengths up to 1500 mm


    OPTIONS

    • Adaptable to further applications e.g. barrel elevation actuator
    • Geometry based on operational needs - various standard bases available for modification
    • Customer-specific material selection & coating - sea-water-resistant and low magnetic permeability available
    • Excellent repeatability and stability
    • Recoil resistant - ultra-high axial stability
    • Lifetime-Lubrication available
